214603 409 Revision A
Figure 5.217: GSL Position
2. Place the ground speed lever (GSL) in N-DETENT (A),
stop the engine, and remove the key.
Figure 5.218: Caster Wheels and Walking Beam
(Engine-Forward View)
3. Raise the end of walking beam (A) until the caster
wheel assembly (B) is slightly off the ground. Use a
suitable lifting device, capable of lifting 2268 kg
(5000 lb.) minimum.
4. Place a jack stand beneath the walking beam and lower
the beam until resting on the stand.
MAINTENANCE AND SERVICING
