214603 471 Revision A
Cummins
Fault
Code
J1939
SPN
J1939
FMI
Lamp
J1939 SPN
Description
Cummins Description
62
2292 611 16 Amber Fuel inlet meter device Fuel inlet meter device — data valid but
above normal operational range —
moderately severe level
2293 611 18
Amber Fuel inlet meter device
Fuel inlet meter device flow demand lower
than expected — data valid but below
normal operational range — moderately
severe level
115 612 2
Red
System diagnostic
code #2
Engine speed/position sensor circuit lost
both of two signals from the magnetic
pickup sensor — data erratic, intermittent, or
incorrect
244 623 4 Amber Red stop lamp Red stop lamp driver circuit — voltage below
normal, or shorted to low source
1117 627 2 Power supply Power lost with ignition on — data erratic,
intermittent, or incorrect
351 627 12
Amber
Controller #1
Injector power supply — bad intelligent
device or component
111 629 12
Red
Controller #1
Engine control module critical internal
failure — bad intelligent device or
component
343 629 12 Amber
Controller #1
Engine control module warning internal
hardware failure — bad intelligent device or
component
341 630 2 Amber
Calibration memory
Engine control module data lost — data
erratic, intermittent, or incorrect
342 630 13 Red
Calibration memory
Electronic calibration code incompatibility
— out of calibration
2217 630 31
Amber
Calibration memory ECM program memory (ram) corruption —
condition exists
2311 633 31 Amber
Fuel control valve #1
Fueling actuator #1 circuit error —
condition exists
285 639 9 Amber
SAE J1939 datalink SAE J1939 multiplexing PGN timeout error
— abnormal update rate
286 639 13
Amber
SAE J1939 datalink SAE J1939 multiplexing configuration error
— out of calibration
599 640 14 Red Engine external
protection input
Auxiliary commanded dual output shutdown
— special instructions
237 644 2 Amber External speed input
External speed input (multiple unit
synchronization) — data erratic, intermittent,
or incorrect
REFERENCE
62. The descriptions of Cummins J1939 SPN codes are subject to change at their discretion.
