214603 69 Revision A
The autosteer engagement switch harness has two connectors and is located as follows:
1014371
A
Figure 3.55: Autosteer Harness SW1
GSL SW1 (A) is located in the cab, beneath the floor mat at
the engine-end seat position switch.
1000881
A
Figure 3.56: Autosteer Harness SW2
GSL SW2 (A) is located beneath the cab, between the fuel
tank and evaporator box.
OPERATOR’S STATION
