Command Reference
R&S
®
ZNB/ZNBT
1008User Manual 1173.9163.02 ─ 55
Parameters:
<BinValue> 0 - high
1 - low
*RST: n/a (default: 0)
Example:
CONT:HAND:OUTP2:DATA 0
Set the /OUTPUT2 line (pin 4) to 0 (current state of /
OUTPUT2).
CONT:HAND:OUTP2:USER 1
Define the next state of the /OUTPUT2 line as 1 (low). /
OUTPUT2 will go from 0 to 1 when the analyzer receives a neg-
ative pulse on the /INPUT1 line (pin 2).
CONTrol:HANDler:PASSfail:LOGic <Logic>
Specifies the the logic of the /PASS FAIL line (pin 33) of the Universal Interface.
Parameters:
<Logic> POSitive | NEGative
POSitive – high meas PASS, low means FAIL
NEGative – low meas PASS, high means FAIL
Note:*RST or "Preset" do not change the configuration of the
Universal Interface. Use CONTrol:HANDler:RESet to restore
default values.
*RST: n/a (default: POSitive)
Example: See CONTrol:HANDler:PASSfail:MODE
CONTrol:HANDler:PASSfail:MODE <Mode>
Specifies the default logical pass/fail state and the timing of the /PASS FAIL line (pin
33). The /PASS FAIL STROBE (pin 36) is set after the /PASS FAIL line; see Chap-
ter 11.3.4.4, "Timing of Control Signals", on page 1438.
If the mode is PASS or FAIL, the /PASS FAIL line is returned to its default state when
the analyzer is ready for a new measurement (/READY FOR TRIGGER).
Parameters:
<Mode> NOWait | PASS | FAIL
NOWait – the /PASS FAIL line is set as soon as a failure condi-
tion occurs.
PASS – the line stays in PASS state (as defined by CONTrol:
HANDler:PASSfail:LOGic) until a sweep end condition
(determined by CONTrol:HANDler:PASSfail:SCOPe)
occurs.
FAIL – the line stays in FAIL state until a sweep end condition
occurs.
Note:*RST or "Preset" do not change the configuration of the
Universal Interface. Use CONTrol:HANDler:RESet to restore
default values.
