Command Reference
R&S
®
ZNB/ZNBT
1095User Manual 1173.9163.02 ─ 55
Manual operation: See "Add / Add All... / Replace / Apply / Apply to All"
on page 498
MMEMory:STORe:CORRection:TCOefficient<Ch> <PmclFile>
Saves the power meter (two-port) transmission coefficients of channel <Ch> to a
power meter correction list file.
Suffix:
<Ch>
.
Channel number
Setting parameters:
<PmclFile> String parameter specifying the name and directory of the cre-
ated power meter correction list file. The file extension *.pmcl
is mandatory.
If no path is specified, the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
*RST: n/a
Example: See SOURce<Ch>:POWer<PhyPt>:CORRection:
TCOefficient:CALibration
Usage: Setting only
Manual operation: See "Recall... / Save..." on page 494
MMEMory:STORe:EYE:MASK <TraceName>, <TraceFile>
Stores a user-defined eye mask to a 7bit ASCII file.
Setting parameters:
<TraceName> Name of the related eye diagram
<TraceFile> String parameter containing the path and file name of the eye
mask file. If the path is omitted, the current directory is used (see
MMEMory:CDIRectory).
Usage: Setting only
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Save / Load Mask Configuration" on page 654
MMEMory:STORe:EYE:MASK:RESults <TraceName>, <TraceFile>
Saves the detailed results of the mask test in the related eye diagram to an ASCII file
(see CALCulate<Chn>:EYE:MASK:DATA? on page 807).
This command will raise an execution error if CALCulate<Chn>:EYE:MASK:STATe is
OFF.
Setting parameters:
<TraceName> The name of the eye diagram whose mask test results shall be
exported
