Manual operation: See "Apply" on page 437
[SENSe<Ch>:]CORRection:COLLect:SCONnection<PhyPt> <Type>[, <Gender>]
Selects a connector type at a specified port <PhyPt> and its gender. In contrast to
[SENSe<Ch>:]CORRection:COLLect:CONNection<PhyPt>, this command uses
a string variable to identify the connector type.
Suffix:
<Ch>
.
Channel number of the calibrated channel
<PhyPt> Port numbers of the analyzer. If the analyzer is set to use the
same connectors at all ports ([SENSe<Ch>:]CORRection:
COLLect:CONNection:PORTs ALL), then a change of a con-
nector type is valid for all ports. The gender of the connectors
can still be different.
Parameters:
<Type> Connector type (string parameter) of the connectors. See "Cal
kit naming conventions" under [SENSe:]CORRection:CKIT:
<ConnType>:SELect.
*RST: 'N 50 Ohm',FEM for all ports.
<Gender> MALE | FEMale
Gender of the connectors. The gender designation is not neces-
sary (and ignored) for sexless connector types.
Example:
*RST; :CORR:COLL:SCON1 'N 75 Ohm', MALE; SCON4?
Change the connector type at port 1 from 'N 50 Ohm', FEM to 'N
75 Ohm', MALE. The connector type at the other ports is also
changed to N 75 Ohm, however, the gender (female) is main-
tained. CORR:COLL:SCON4? returns 'N 75 Ohm', FEM.
Manual operation: See "Connector / Gender" on page 433
[SENSe<Ch>:]CORRection:CONNection <ConnectorName>[, <Mode>, <Gender>,
<RelPermittivity>, <RefImpedance>]
Configures the user-defined connector types.
Suffix:
<Ch>
.
Channel number
Parameters:
<ConnectorName> Name of the user-defined connectors, string parameter.
<Mode> TEM | WGUide
Transverse electric or waveguide type propagation mode.
<Gender> GENDer | NGENder
GENDer – polar connector type (m/f)
NGENder – sexless connector type
