GUI Reference

R&S

ZNB/ZNBT

606User Manual 1173.9163.02 ─ 55

The symbol selects "no network" and disables deembedding/embedding for the

selected balanced port.

The 4-port data network (symbol "D1" only) is defined by means of an s4p file (see D1,

D2). For deembedding, the s4p file can also be generated by a third-party fixture mod-

eling tool (see "Fixture Tool" on page 589).

Other 2-port data-subnetworks (symbols "D1" and "D2") are defined by means of s2p

files (see Network).

The parameters of lumped elements are displayed below the graphical list.

Tip:

●

Drag and drop the network symbols in horizontal or vertical direction to switch to

the next symbol. The lumped elements and S-parameter networks ("D1", "D2") are

numbered from top to bottom.

●

Use the Conductance in Embedding Networks switch to change from resistances

in "Capacitor in parallel with resistor" circuit blocks to conductances and vice versa.

Remote command:

CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:

TNDefinition

CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:

PARameters:C<Cmp>

CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:

PARameters:L<Cmp>

CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:

PARameters:R<Cmp>

CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:

PARameters:G<Cmp>
