Return values:
<Data> Response values either in ASCII or block data format, depend-
ing on the current FORMat[:DATA] setting.
Example: Analogous to CALCulate:DATA:DALL?; see
CALCulate<Chn>:DATA.
Usage: Query only
CALCulate:DATA:TRACe <TraceName>, <Format>, <Data>...
The query gets the trace data of an arbitrary (not necessarily the active) trace, refer-
enced by its trace name <TraceName>.
The "set direction" allows to import formatted or unformatted trace data to an existing
trace (data access point 3 or 2 in Chapter 5.1.5, "Data Flow", on page 89).
Note
●
Unformatted trace data (SDATa) can only be imported to memory traces
●
Formatted trace data (FDATa) can only be imported to "live" traces if the related
channel is in single sweep mode (INITiate<Ch>:CONTinuous OFF).
Before the import, the target trace must be prepared according to the settings used
during export. Any request for new data from the hardware ("Restart Sweep" in sin-
gle sweep mode or switching to continuous sweep mode) discards imported data
and switches back the display to measured data.
Parameters:
<TraceName> String parameter containing the trace name
<Format> FDATa | SDATa | MDATa | NCData | UCData
Data format; see Table 8-2.
<Data> Trace data for FDATa | SDATa import either in ASCII or block
data format, depending on the current FORMat[:DATA] setting.
The column order must match the one used during export.
Example: See CALCulate<Chn>:DATA.
CALCulate<Ch>:DATA:CALL <Format>, <Data>...
The query reads the current response values of all S-parameter data traces at channel
<Ch>'s data access point <DACPoint>.
If a full n-port system error correction is active in the related channel, the command
reads the full nxn S-matrix of the calibrated ports (there is no need to create or display
the S-parameter traces). Use CALCulate<Ch>:DATA:CALL:CATalog? to query the
available traces.
The "set direction" allows you to import measurement data at the "Fixture Simulation
Input" data access point (see Chapter 5.1.5, "Data Flow", on page 89).
