R&S ZNB - Page 964

Command Reference
R&S
®
ZNB/ZNBT
964User Manual 1173.9163.02 ─ 55
Parameters for setting and query:
<CircuitModel> SL | SC
Possible circuit models (character data); see Table 8-8.
Example:
*RST; :CALC:TRAN:VNET:GLO:DEEM:PAR:R? SC; R? SL
Query the default resistances for ground loop deembedding. The
response is 10000000; 0.
CALC:TRAN:VNET:GLO:DEEM:PAR:R SC, 2.2E+3
Increase the resistance for the Shunt C model to 2.2 kΩ.
Manual operation: See "Network" on page 608
CALCulate<Ch>:TRANsform:VNETworks:GLOop:DEEMbedding<group>:
TNDefinition <CircuitModel>
Selects the circuit model for ground loop deembedding.
Suffix:
<Ch>
.
Channel number.
<group> Port group (DUT) number.
If multiple port groups are configured (see SOURce<Ch>:
GROup<Grp>:PPORts) and CALCulate<Ch>:TRANsform:
VNETworks:GLOop:GROup is ON, then each port group can
have its own de-/embedding models.
Parameters:
<CircuitModel> FIMPort | SL | SC | SG
Possible circuit models (character data); see Circuit models for
ground loop port embedding/deembedding.
Example: See CALCulate<Ch>:TRANsform:VNETworks:GLOop:
DEEMbedding<group>[:STATe] on page 961
Manual operation: See "Network" on page 608
CALCulate<Ch>:TRANsform:VNETworks:GLOop:EMBedding<group>[:STATe]
<Boolean>
Enables or disables the embedding function for ground loops. It is allowed to change
the circuit model and its parameters while embedding is enabled.
Suffix:
<Ch>
.
Channel number.
<group> Port group (DUT) number.
If multiple port groups are configured (see SOURce<Ch>:
GROup<Grp>:PPORts) and CALCulate<Ch>:TRANsform:
VNETworks:GLOop:GROup is ON, then each port group can
have its own de-/embedding models.
SCPI Command Reference
