Parameters:
<Conductance> Conductance G<i> for the specified circuit model.
Range: -1kS to 1 kS.
Increment: 1 pS (1E-12 S)
*RST: 0 S
Default unit: Siemens (SI unit symbol: S)
Parameters for setting and query:
<arg0> STSG | SGST | GSSL | LSSG | GSSG | SLGS | SGLS | SGGS
Circuit model whose conductance G<i> shall be set, see
Table 8-6
Manual operation: See "Network" on page 602
CALCulate<Ch>:TRANsform:VNETworks:PPAir:EMBedding<ListId>:TNDefinition
<CircuitModel>
Selects the circuit model for port pair embedding.
Suffix:
<Ch>
.
Channel number
<ListId> Index of the affected port pair (see CALCulate<Ch>:
TRANsform:VNETworks:PPAir:EMBedding<ListId>:
DEFine)
Parameters:
<CircuitModel> FIMPort | STSL | STSC | SLST | SCST | CSSL | LSSC | CSSC |
LSSL | SLCS | SCLS | SCCS | SLLS | STSG | SGST | GSSL |
LSSG | GSSG | SLGS | SGLS | SGGS
Circuit model to be used for the addressed port pair, see
Table 8-6
Example: See CALCulate<Ch>:TRANsform:VNETworks:PPAir:
EMBedding<ListId>[:STATe]
Manual operation: See "Network" on page 602
CALCulate<Ch>:TRANsform:VNETworks:PSET:DEEMbedding<ListId>:DEFine
<Port1>, <Port2>[, <Port3>[, <Port4>]]
CALCulate<Ch>:TRANsform:VNETworks:PSET:EMBedding<ListId>:DEFine
<Port1>, <Port2>, ...
Defines port set <ListId> for port set deembedding|embedding.
Note that port pairs (i.e. 2-element port sets) can also be created using
CALCulate<Ch>:TRANsform:VNETworks:PPAir:DEEMbedding<ListId>:
DEFine / CALCulate<Ch>:TRANsform:VNETworks:PPAir:
EMBedding<ListId>:DEFine.
