A3/11"x17" Tray Unit TK5000 (B331-11)
SM 1-41 B234/B235/B236/D101/D102/D103
Installation
9. From the left tandem tray, remove the front cover [A] ( x 2).
10. Pull out the right tandem tray [B] then remove it. ( x 2).
B331I002A.WMF
B331I709.WMF
[A]
[B]
