Trimble S - Page 244

Chapter 5
Maintenance and Repair
Trimble S, VX, SPS & RTS Service Manual5 - 58 P/N 57150002, Revision 5.0
F
9 Mount MSB board
incl. motor winding.
See page 5-62.
10 Mount horizontal
angle disc.
See page 5-59.
11 Mount SRC board incl.
magnets.
A. Mount the magnet
holder, See page 5-59
B. Connect cable to
magnet holder.
C. Mount tube, see Fig. 5-
54 on page 5-57 .
D. Mount lid, see Fig. 5-
54 on page 5-57 .
When mounting
the tube make
sure that the
cable is
stretched at the
magnet holder
side.
55 Ncm.
Use a torque wrench
with a torx T8 bit.
12 Mount horizontal
turning unit.
See page 5-55
Item Performance Action Results Notes
