Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 75 Trimble S, VX, SPS & RTS Service Manual
F
Fig. 6-80 Test receiver diode (APD) amplification
7 Exit
APD / Reference
fibre
software.
A. The software MUST
be terminated by
clicking the
EXIT
button.
B. Click
OK button,
instrument will exit
service mode and be
restarted.
Fig. 6-81 Reference fibre check, exit info
Fig. 6-82 APD / Reference fibre software, exit info
