Chapter 6
Adjustment and verification
P/N 57150002, Revision 5.0 6 - 135 Trimble S, VX, SPS & RTS Service Manual
F
Fig. 6-145 Tracker receiver
Fig. 6-146 Four quadrant detector
7 Check adjustment Repeat adjustment until
the tracker receiver is
aligned to the instruments
cross-hairs.
If not, then repeat item 6.
Item Performance Description Result Notes
A&C
50 Ncm /
4.43 lbfin
A& C
A&C
A&C
Tracklight
C
B
