Trimble S, VX, SPS & RTS Service ManualVIII P/N 57150002, Revision 5.0
F
2.2 June 2007
Changes
• Regreasing of vertical axes, see page 5-50
• Firmware compatibility, see page 3-54
• Part numbers for RoHS compliant parts added, see page 8-1
• Troubleshooting updated, See page 4-1
• Baselines added, see page 8-46
• Tracker transmitter divergence adjustment added, see page 6-139
• Vertical oscillation compensation updated, see page 6-25
• Firmware upgrade updated, see page 6-31
3.0 April 2008
Changes
• Trimble VX service information added
• Trimble SPS service information added
• Trimble S8 service information added
• Check list after service/repair for each model implemented, see page 6-
203
• Event log analysis implemented, see page 4-3
• Clear event log instruction implemented, see page 4-4
• Troubleshooting flow chart added, see page 4-13
• Service interval function implemented, see page 3-104
• Check/adjustment of reference fibre for DR300+ added, see page 6-72
• Saving and initializing 1” Horizontal Turning Unit constants added, see
page 6-6
• Instruction how to replace reference greywedge added, see page 5-81
• Vertical oscillation compensation software updated, see page 6-25
• Radio short range test from Service Bulletin JE-1007-0046 added, see
page 6-4
• Trunnion axis correction instruction added, see page 6-48
• Removal of Cover objective instruction added, see page 5-135
4.0 April 2009
Changes
• Trimble S8 service information for Long range FineLock & High Power
Laser pointer added
• New Trimble SPS model SPS630added
• Trimble RTS service information added
• Instrument model matrix implemented, see page 2-14
• Prism requirements for EDM offset determination added, see page 8-46
• PASS release 1.6.3 information, see page 7-5
• New function in PASS, Basic Function Test, see page 4-4
• New function in PASS, read out PIN code from instrument (S8 VX &
SPS), see page 6-178
• Software configuration key installation information implemented, see
page 6-201
• Name of Pliobond changed to Glue MS 1855, see page 8-30
