6. EM GUI orientation
6.39 Settings Menu > Web App area
General
Main work area of the Setting Menu, where the user has access to a s et of functions directly provided by the Event Master ser ies
processor.
All of the functions described in this section can also be performed by launching the web app directly from
the brow ser outside of the GUI. You need to type the unit’s IP address into your browser’s address bar and
the Web ap p will appear in the b row ser.
Description
There a re several tabs in this area:
• Dashboard: The four s ubmenus in the D ashboard window provide access t o card diagnos tics software.
• Tools: T his menu allows us ers to Download software and perform B ackup and Restore operations.
• Help: This menu contains a list of frequently asked questions to help you implement your system.
• Contact us: Display information to Barco tech support.
• Follow us: Display links to obtain more information about image processing and Barco.
The following sections describe each tab of this area in detail:
• "Settings Menu > Web App area > Dashboard", page 207
• "Settings Menu > Web App area > Tools", page 211
• "Settings Menu > Web A pp area > Help", page 2 16
• "Settings Menu > Web App area > Contact us", page 217
• "Settings Menu > Web App area > F ollow us", page 218
206
R5905948 EVENT MASTER DEVICES 17/07/2017
