Barco S3 User Manual

A. Specifications
A.5 Specifications of EX
EX Specifications
Video inputs 2 card slots, which can be either input or output
• Up to 8 inputs using any of th e Event Master input cards
• Input distribution to other processors via the link cable or a locally installed output card
Video outputs 2 card slots, which can be either input or output
• Up to 8 outputs using any of the Event Master input cards
• Output so urcing from other processors via the link cable or a locally installed input card
Genlock Analog r eference input on BNC connector
• Blackburst and Bi-level at SD, Tri-level at HD
• Reference output provided by internal sync generator capable of Bi-level and Tri-level
sync s ignals
Program output
Up to 8 program ou tputs for destinations created in a linked E2 or S 3-4K processor
Scaled AUX ou tputs U ser definable up to 8x 2048 × 1200 at 60 Hz or 2x 4K at 60 Hz
Output color correction
Still stores
Up to 100 HD stills available in AUX
Expandability
• Easily expandable for larger display applications via proprietary links
• 2 Ex c hassis can be linked for s tandalone operation, or an EX can be linked to either
an E 2 or a n S3–4K.
HDCP HDCP compliant
Control
• Event Master screen m anagem ent software for PC or MAC
• Ethernet RJ-45, 1000/100/10 Mbps autosense
Service ability
• Field-serviceable I/O and processing cards ( not hot-swappable)
Dimensions
• Height: 4.37 cm (1.72 in.) – 1RU rackmount
• Width: 48.26 c m (19 in.)
• Depth: 40.41 cm (15.91 in.)
Weight
5.53 kg / 12 .2 lbs
Power
• Input power: 100 – 240 VAC 50/60 Hz 125 W
Warranty
• 3 year s parts and labor
