6. EM GUI orientation
6.22 Programming Menu > Adjustment area
General
Situated on the right hand side of the screen is the Adjustment area. In this a rea users can configure Layers and Sources and
create User keys and Preset s.
Description
There a re several tabs in this area:
• Layers : Provides a list of the destinations. Under each des tination a list of assigned lay ers and the back ground is provided.
• User Keys : Provides a list of user k eys. User keys contains all (or a portion) of the current layer’s attributes (such as border
color, size, effects, etc.). User Keys are not applicable for AUX Destination.
• Presets : List of Presets. Presets contains a group of Destination worth of information.
Note: Not all settings com posing a layer is a layer se tting, but a Source File setting. Be aware that for desired res ult a USER
KEY might have to be bound to a preset.
• Adjustment : Based on what is selected in the Preview or Program canvas area, this is the panel where w e are a djusting what
is selected. For example if we select Layer1, we will be adjusting Layer1 settings.
• Source Adjustment: This p anel is sho wn on the A djust panel when a layer with a v alid Source is selected.
At the bottom of the area, the re is a set of buttons allowing execute transition actions on selected Destinations.
The following sections desc ribe each panel of this are a in detail:
• "Programming M enu > Adjustment area > Layer configuration", page 171
• "Programming Men u > Adjus tment area > Back ground configuration", page 182
• "Programming Me nu > A djustment area > User Keys configuration", page 184
• "Programming M enu > A djustment area > P resets configuration", p age 186
• "Programming M enu > Adjustment area > Source adjustment", page 1 89
• "Programming Menu > Adjustment area > Global Transition Rate/Trans/Cut", page 191
170
R5905948 EVENT MASTER DEVICES 17/07/2017
