A. Specifications
A.2 Specifications of E2 Jr.
E2 Jr. Specifications
Video inputs
16 inputs via 4 input cards (Event Mas ter series cards)
• Up to 4 x 4K inputs - eac h input c ard supports up to 4K @60p
• 4 x SD/HD/3G SDI (6G rea dy)
• 6 x HDM I 1.4a (297 Mpix/sec max)
• 6 x DisplayP ort 1.1 (330 Mpix/sec max)
Video outputs
10 outputs via 3 output cards (Event Master series car ds)
• Up to 2 x 4K outputs - each output card supports up to 4K@ 60 p
• 4 x SD/HD/3G SDI (6G rea dy)
• 4 x HDM I 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
Genlock Analog reference input/loop on BNC connec tors; bi-lev el and blac kburst at S D and
tri-level a t HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output
4 program outputs configur able as single screens or tiled/blended widesc reens
•Configurable from 4X 2048X1200@60 max to 1 x 4096x2400@60 max
• Independent edge blending/feathering control for all four sides
Scaled Aux outputs User defi nable from 4 x 2048x 1200@ 60 to 1 x 4K@6 0
All outputs can be define d as A ux destinations for a total of 8 Aux outputs
Output color correction
Mixers
• Native resolution background mixer per output screen
• Independent layer transitions o r full P review/Program transition
• Flexible layer allocation – up to 8 m ixable or 16 single scalable PIP/key layers
assignable to Program output s creens
Still stores
Up to 100 HD stills available in background, A ux or PIP
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma key
• PIP moves via Keyframes
Multiviewer
• Flexibl e user-d e finable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware same E2 Event Master Processors
Expandability Linking is available as an upgrade option
HDCP HDCP c ompliant
Control
• Event Master screen management software for PC or MAC
• Ethernet RJ -45, 1000/100/10 Mbps autosense
Serviceability
• Field-serviceable I/O and processing cards (not hot-sw appable)
• Hot-swappable dual-redundant power supplies
Dimensions
• Height: 17.8 cm (7.0 in) - 4 RU rackmount
• Width: 43.2 cm (17 in) without chassis handles , 48.3 cm (19 in) with chassis
handles attached
• Depth: 56 .9 cm (22.4 in) from front panel to rear p anel, 62.2 cm (24.5 in) overall
Weight
27.8 kg / 61 lbs
494 R5905948 EVENT MASTER DEVICES 17/07/2017
