13. E2 Maintenance
13.12 Front Panel Knob
Image 13-27
Before yo u p roceed removing the Front pan el knob you need to remo ve the F ront Co ver A ssemb ly as outlined
in the related procedure.
Necessary tools
• Knob r emoval tool provided by B arco
Image 13-28
• Flat head screwdriver or a tool with a sharp edge
How to remove the Front Panel Knob
1. Remove the knob cover with a flat screw driv er or a sharp object to expose the inside of the knob.
Image 13-29
2. Use the knob removal tool pr ovided by Barco to take out the knob. Align the notches on the tool with the grooves in the knob as
indicated below.
Note: If the tool is not av ailable use fine point needle nose pliers to squee ze at knob between the two grooves while pulling it
out.
366
R5905948 EVENT MASTER DEVICES 17/07/2017
