7. System Setup
7.24 Programming Menu > Drop Inputs to A ux Destinations
General
In this procedure, y ou will dr op Inputs into Aux Destinations.
Prerequisite
• Ensure that you are familiar with the Programming M enu. F or details on this menu, please refer to chapter "Programming
Menu", page 149.
Drop Layers into Screen Destinations
1. Make sure the Aux Destination is vis ible in the w orkspace by selecting the prop er layout or view.
2. On the left hand side click on the Inputs tab.
3. Drag any Input Source into the preview screen of the Aux destination.
(Optional) Additional Adjustments
1. If the Aux is supposed to toggle between P review and Pr ogram, click the Toggle button in the top of the Destinations Preview
2. A source can be dropped into the Program of an A ux if the Pro gram is Un-Locked. Un-lock the P rogram by clicking on the small
white lock in the bottom of the Destination.
R5905948 EVENT MASTER DEVICES 17/07/2017
251
