14. S3 Maintenance
14.19 Front Rack-Ears
Image 14-45
Concerned parts
R767281K FRO NT RACK EA RS S3
Necessary tools
1 x Phillips Screwdriver #2
How to remove Side R ack-Ears
1. Loosening and removing the six (three on each s ide) pan head screws that secure the R ack Ears to the cha ssis s ides.
Image 14-46
2. Remove the Rack E ars from the Chassis.
Note: If the front face an d the front brackets were not removed be fore this step, the entire of these elements will be automatically
detached from the c hassis when you remov e the Front Rack Ears. The front brac kets are fixed on the Front Rack E ars,
not on the chassis.
How to install Side Rack-Ears
To install the Side Rack-Ears follow the sam e procedure in the rever
se order.
R5905948 EVENT MASTER DEVICES 17/07/2017
445
