Barco S3 User Manual

14. S3 Maintenance
14.3 Spare Parts Serviceable b y all users
S3 Spare Parts list
P/N
Description
Comments
R767241K *
VFD Display assemb ly
R767246K *
VFD F ilter
R767260K *
Front Panel board
R767263K * Heatsink fan One for each Input, Output, Link and VPU card
R767264K * CPU m odule
R767265K * Motherboard Heatsink & Fan kit
R767267K * Power supply(PS) One PS only. Sys tem accepts two Power supplies
R767275K * Solid-State Me mory
R767278K
MOTHERBOARD S3
R767279K
POWER INTERPOSER S3
R767280K * 3RU fan tray The fans are not available separately — will replace R767271K
R767281K
FRONT RAC K EAR S S3 Includes hardware for both sides
R767282K
REAR CONNECTOR
PROTEC TOR S3
R767283K
S3 Cable Kit
Kit contains:
• 1x U SB Extension cable
• 1x Fan Tray-to-Motherboard cable
• 1x RJ45-to-Motherboard CAT5 Ethernet cable
• 1x Front Panel Keyboard-to-Motherboard flat c able
• 1x Genlock-to-Motherboard flat cable
• 1x VFD-to-Motherboard cable
V327007 * System Battery
R9004740 * DVI Input B oard
R9004741 * SDI Output Boar d
R9004742 * SDI Input B oard
R9004743 * HDMI O utput Board
R9004744 * DP/HDM I Input Board
R9004745 * D VI Output Boar d Not available in release 1
R9004746 * Link Card Board
R9004750 * Link/CXP Cable
R9004758 VPU C ARD S3
R9004759 GENLOCK S3
R9004760 GENLOCK/S3D S 3
(*) commo n between E2 and S3.
Optional CXP C ables
P/N
Descrip tion
Comments
R9004753
CXP Fiber Cable
1x 30M Fiber ca ble
R9004754
CXP Fiber Cable
1x 100M Fiber cable
R9004761
CXP Cable
1x 3M cable
R9004762
CXP Cable
1x 5M cable
R9004763
CXP Cable
2x 3M cables
R9004764
CXP Cable
2x 5M cables
R5905948 EVENT MASTER DEVICES 17/07/2017 419
