Barco S3 User Manual

A. Specifications
A.9 Specifications of standard connections
Standard connection specifications
DisplayPort (DP)
• Per DP 1.1a specification
• On DP connector
• Formats up to 2,560 × 1,600 at 60 Hz and 3,840 × 1,200 at 60 Hz (30 bits)
• 4K/UHD supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L a nd R half), or 4x DP
(quadrants)
- 3,840 × 2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 via 1x D P, 2x DP (L and R half) or 4x DP
(quadrants)
- 4,096 × 2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096 × 2,400/23.98/24/25/29.97/30/50/59.94/60 via 2x DP (L and R half) or 4x DP
(quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
DVI
• Per DVI 1.0 specification
• DVI D igital video on DVI-I connector
• All single-link DVI formats up to 165 MHz
• All dual-link DVI form ats up to 330 MHz
• Maximum H Active: 4,096; Maxim um V Active: 3,072
• 4K/UHD Supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 input via 1x DV I-DL, 2x DVI-SL (L and R half) or
4x DV I-SL (quadrants)
- 3,840 × 2,160/50/59.94/60 input via 2x DVI-DL (L and R half) or 4x DV I-SL (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 input via 2x DVI-SL (L a nd R half) or 4x DVI-S L
(quadrants)
- 4,096 × 2,160/50/59.94/60 input via 2x DVI-DL (L and R half) or 4x DV I-SL (quadrants)
- 4,096 × 2,400/23.98/24/25/29.97/30 input via 2x DVI-SL (L a nd R half) or 4x DVI-S L
(quadrants)
- 4,096 × 2,400/50/59.94/60 input via 2x DVI-DL (L & R half) or 4x DVI-SL (quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
HDMI
• Per H DMI 1.4a specification
• On HDMI connector (Ty pe A )
• Formats up to 2,560 × 1,600 at 60 Hz and 3,840 × 1,200 at 60 Hz (30 bits)
• 4K/UHD Supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 input via 1x H DMI, 2x HDMI (L and R half) or 4x
HDMI (q uadrants)
- 3,840 × 2,160/50/59.94/60 input via 2x HDMI (L and R half) or 4x HDMI (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 input via 1x H DMI, 2x HDMI (L and R half) or 4x
HDMI (q uadrants)
- 4,096 × 2,160/50/59.94/60 input via 2x HDMI (L and R half) or 4x HDMI (quadrants)
• EDID version 1.3 compatible
• HDCP version 1.4 compatible
SDI
• SD/HD/3G SDI (6G read y) on BNC connector
•Formats:
- SD Formats: SD -SDI per SMPTE 259M-C (NTSC/PAL resolution)
- HD Formats: H D-SDI per SM PTE 274 M, 296M, 2048
- 3G Form ats: 3 G-SDI per SMPTE 424M, Barcolink
• 6G Ready (via future firmwar e up grade)
• 4K/UHD Supported:
- 3,840 × 2,160/23.98/24/25/29.97/30 input v ia 4x HD-SDI (quadrants)
- 3,840 × 2,160/50/59.94/60 input via 4x 3G-SDI (quadrants)
- 4,096 × 2,160/23.98/24/25/29.97/30 input v ia 4x HD-SDI (quadrants)
- 4,096 × 2,160/50/59.94/60 input via 4x 3G-SDI (quadrants)
504 R5905948 EVENT MASTER DEVICES 17/07/2017
