4. Hardware orientation
3 Genlock BNC Input and Output
––
5 Expansion Links
––
7 Input cards (HDM I/DP, SDI, DVI)
8 Outp uts cards (DVI, SDI)
8 Multiviewer card (HDMI)
––
10 USB 2.0 port
The EX image in imag e 4-7 is an exam ple o nly. The EX expansion box d oes no t ship with cards; ca rds must
be purchased separately.
Description E2 E2 Jr.
S3–4K S3–4K Jr.
EX
1
AC c onnectors
22211
2
RJ-45 connector for 10/100 BaseT Ethernet
communications
11111
3
Genlock Input BNC with passive Loop-through
2222NA
1
4
S3D In and S3D Out 4 In, 2 Out 4 In, 2 Out 4 In, 2 Out 4 In, 2 O ut
NA
5 E xpansion Link cards 2 NA
2
1NA
2
NA
3
6VPUcards NA NA 2 1 NA
7
Input cards (HDMI/DP, SDI, DV I)
8432≤ 2
4
8
Outputs cards (DVI, SDI)
4332≤ 2
4
9
Multiviewer card (HD M I)
1111≤ 1
4
10
USB 2.0 port
NA NA NA NA 1
Tabl e 4 -2
Comparison of Event Master rear-panel connections
1
The EX expansion box internally generates genlock output.
2
E2 Jr. and S3–4K Jr. do not have expansion L ink cards.
3
The EX has two (2) Expansion Links integrated in the ch assis.
4
Each EX expansion box has two general purp
ose card slots , each of which may support any E2 input or
output card.
AC connectors
Event M aster E2, E2 J., S3–4K , and S3–4K Jr. series processors are equipped w ith tw o r edundant power supp lies. During norm al
operation the load is sha red equally by both supplies. If one supply fails, the second c arries the whole load. Two AC Connector are
provided to connect Event M aster seri
es processors to your facility’s AC power s ource through the supplied power cords.
Input Power Specification: 100-240 VAC, 47-63 Hz
On each power supply there are 3 LED lights that provide status information as follows:
• DC Output Pow er LED: when G reen, the sup
ply is outputting v alid DC power.
• Status LED: when amber indicates that an error has occurred.
• AC Input P ower LED: when green it indicates that the supply is connected to a valid AC power.
Therefore, during normal operating c onditions, the input AC and O utput DC LEDs will turn green.
Note that the power supp lies are installed up side down in the E2 mo del, so the silkscreen markings will also ap-
pear up side down. Power su pplies in the S3 m odel are installed in the correct orientation for reading silkscreen
markings.
Ethernet port
One RJ-45 connector is provided for 10/100BaseT Ethernet comm unications with the E vent Master series processor. The port is
used for running the Web Interface and for connection to an external device.
The E thernet connector is com patible with:
• Standard R J-45 Ethernet cables
• Neutrik EtherCon® series cables
46
R5905948 EVENT MASTER DEVICES 17/07/2017
