9. General operation example
9.1 Event requirements
Description
Inputs for the event are provided from a Windows PC, two AJA K iPROs file recorders, a n Apple M acbook and two video cameras.
Several outputs are required as follows:
• Two program outputs for the projectors dedicated to the Main sc reen. Tw o PIPs are dis played that are equal in size and a re
side-by-side. Tw o looks are desired:
- One look displays the two video clips simultaneously from the KiPROs.
- The other look s hows the PowerPoint and the stage camera.
- Background will be provided from a P C dual-head card.
• Single Screen S ite S creen: Displays the videos from two K iPRO S and two cameras. The images are a lways full s creen and
transition on screen at 0.5 sec.
• A DSM monitor is required for camera adjustments.
• Two 2 monitors for multi-viewing.
Image 9-1
262 R5905948 EVENT MASTER DEVICES 17/07/2017
