A.1 Specifications of E2
E2 Specifications
Video inputs
28 inputs via 8 input cards (Event Mas ter series cards)
• Up to 8 x 4K inputs - eac h input c ard supports up to 4K @60p
• 8 x SD/HD/3G SDI (6G rea dy)
• 8 x HDM I 1.4a (297 Mpix/sec max)
• 8 x DisplayP ort 1.1 (330 Mpix/sec max)
• 4xDualLinkDVI(330)
Video outputs 14 outputs v ia 4 output cards (Event Master s eries cards)
• Up to 3 x 4K outputs - each output card supports up to 4K@ 60 p
• 4 x SD/HD/3G SDI (6G rea dy)
• 8 x HDM I 1.4a (297 Mpix/sec max)
• 2 x HDMI 1.4a for Multiviewer (297 Mpix/sec max)
Genlock Analog reference input/loop on BNC connec tors; bi-lev el and blac kburst at S D and
tri-level a t HD
S3D Sync: 4x input Din connector, 2x output Din connector
Program output
8 program outputs configur able as single screens or tiled/blended widesc reens
•Configurable from 8x 2048X1200@60 max to 2 x 4096x2400@60 max
• Independent edge blending/feathering control for all four sides
Scaled Aux outputs User defi nable from 4 x 2048x 1200@ 60 to 1 x 4K@6 0
All outputs can be defined as Aux destinations for a total of 12 Aux outputs
Output color correction
Mixers
• Native resolution background mixer per output screen
• Independent layer transitions o r full P review/Program transition
• Flexible layer allocation – up to 16 mixable or 32 single scalable P IP/key layers
assignable to Program output s creens
Still stores Up to 100 HD s tills available in background, Aux or PIP
Layer effects
• Borders (hard, soft, halo) and drop shadows
• Color effects
• Strobe, H&V flip
• Luma key
• PIP moves via Keyframes
Multiviewer
• Flexibl e user-d e finable layouts
• Monitor all Inputs and Outputs, including Preview and Aux
• Two outputs
• Dedicated hardware same E2 Event Master Processors
Expandability
• Easily expa ndable for larger display applications via proprietary links
• Link units to increase available Inputs and Outputs for larger tiled/blended
widescreen applications
• Expansion via s imple linking - up to 2 chassis
• E2 ships with the ability to link 2 chassis for expansion. Linking additional chassis
will be available in a future software release.
HDCP HDCP c ompliant
Control
• Event Master screen management software for PC or MAC
• Ethernet RJ -45, 1000/100/10 Mbps autosense
Serviceability
• Field-Serviceable I/O and p rocessing cards (not hot-swappable)
• Hot-swappable dual-redundant power supplies
