Barco S3 User Manual

10. Controller orientation
10.6 EC-200 front panel overview
Overview
Image 10-6
1 T -bar 11 Direct selection button group
2
Work light (flexible support)
12
Syntax entry button group
3 Touch scre en 13 Nump a d
4 12 Destination buttons and a contextual display
showing page of Destinations
14
Contextual display button group
5 Lay er buttons and a contextual display s howing
page of Layers
15
Live function button group
6 A ssign buttons in three identical rows that can host
multiple selections and a contextual display showing
page of the Assign button row
16 Arrow button group
7
User-assignable contextual display buttons 17 Trackball with 4 modifi er buttons
8 Cut and All Trans buttons 18 T-bar with Dis able button, All Trans, and Barco Eye
function button
9 S ystem function button group 19 On-screen keyboard button, console lock button,
Save All button
10 Future expan sion button group 20
Rotary encoders, referred to as w he els, with m odifier
buttons
292 R5905948 EVENT MASTER DEVICES 17/07/2017
