Barco S3 User Manual

13. E2 Maintenance
13.4 Rear I/O and Link C ards
Image 13-3
Overview
Image 13-4
1 Chassis
2 I/O and Link Cards
Concerned parts
R9004740 DVI Input
R9004741
SDI O utput
R9004742
SDI In put
R9004743
HDMI Output
R9004744
DP/HDMI Input
R9004745
DVI Output (*)
R9004746
Link Card
(*) Not available in release 1)
Necessary tools
Phillips S crewdr iver #2.
Howtoremoveacard
1. Locate the card you wish to replace.
Note: The re are 14 ca rd s lot s. The first slot on the left is slot 1 and the last slot on the most right position is 14.
2. Loosen and unsc rew the top an d bottom thumbscrews that are holding the card to the chassis.
3. Gently pull the card out o f its slot.
Tip: You may need to wobble it a little bit up or down t o loosen it from the card guides a s you are pulling out.
354 R5905948 EVENT MASTER DEVICES 17/07/2017
