Barco S3 User Manual

14. S3 Maintenance
14.4 Rear I/O, Link and VPU Cards
Image 14-3
Overview
Image 14-4
1 Chassis
2 I/O, Link and VPU cards
Concerned parts
R9004740 DVI Input
R9004741
SDI O utput
R9004742
SDI In put
R9004743
HDMI Output
R9004744
DP/HDMI Input
R9004745
DVI O utput
R9004746
Link Card
R9004758
VPU card S3
Necessary tools
Phillips S crewdr iver #2.
Howtoremoveacard
1. Locate the card you wish to replace.
Note: Thereare9cardslots. Thefirst s lot on the left is slot 1 and the last s lot o n the m ost right position is 9.
2. Loosen and unsc rew the top
and bottom thumbscrews t hat are holding the card to the chassis.
3. Gently pull the card out o f its slot.
Tip: You may need to wobble it a little bit up or down t o loosen it from the card guides a s you are pulling out.
420
R5905948 EVENT MASTER DEVICES 17/07/2017
