6. EM GUI orientation
6.19 Programming Menu > Resources area
General
This part of the Pro gram m ing page allows us ers to manage the available input resources. Sources are c reated and defined from
the available Inputs that were defined on the System Configuration page.
From R elease 1.5 there is Still Stores for Sources, Still Stores for Backgrounds and Destinations for re-entry.
About Sources and Inputs
Source are defined from input signals. Multiple sour ces can be defined from the same input. After a source is defined, then several
attributes can be modified. These attributes are: color adjustments, crop, sharpness and m ask. By def
ault, a source is automatically
created for each Input. Up to 2 56 sources can be c reated form the same input. As w ith inputs, sources can be defined from m ultiple
connectors, ex: 4K or DL DVI and as a single link or dual link.
The multiviewer d isplays input signals not sources.
Few words about Inputs, Sources and Layers
Input
• Definition: Any video signal connected to the Event Mas ter series proce
ssor.
• Features:
- An input signal can be 2K (Single Link), Dual-Link or 4K (Ultra-HD) format.
- Depending on the resolution and type of the input signal, multiple connectors may be required to connect an input signal to
the Ev ent Master series processor. The number of connectors r equired is listed in t he table be low.
2K
Resolutions up to
2048x1200@60
Dual Link
Resolutions up to
3840x1200@60
4K (Ultra HD)
Resolutions up to
4096x2160@60
SDI
124
DVI 112
HDMI 1.4a 1 1 2
DisplayPort1.1a112
• Adjustments:
- Name, Colorspace, Connector capacity, A uto Acquire, EDID, Contrast, Brightness, Gamma.
- Adjustments to an input signal have an effect on all sou rces that are derived from the input signal
Source
• Definition: A video signal created when an input is manipulated to cre ate a desired look.
• Features:
- When an input is created, a source is automatically c reated with the same attributes as the input.
- Multiple sources can be generated from the same input signal.
- Any source c an b e dropped into any layer and an y destination.
- The same s o urce can b e u sed in m ultiple layers and multiple destinations.
- It should be noted that if a source is used in multiple layers and a source is m odified in one of the layers, it will not be
automatically updated in the other layers. To upda te the source in the other layers, it needs to be deleted from these layers
and re-inserted from the sources list.
• Adjustments:
- Name, Bind to User Key, La yer Aspect Ratio, Size, Position, Co ntrast, Brightness an d Hue.
Lay e r
150
R5905948 EVENT MASTER DEVICES 17/07/2017
