3. General
3.2 Event Master series processors features
Inputs
Model E2 E2 Jr.
S3–4K S3–4K Jr.
EX
Input cards 8x 4x 3x 2x 2x
Each card accommoda tes either 4x HD inputs, 2x 2560 x 1600 inputs, or 1x 4K input.
The EX expansion box does not ship with cards; cards must be purchased separately. Each EX expansion box has
two g eneral
purpose card slots, each of which may support any E2 input or o utput card.
Card type Connector Type
HDMI/DisplayPort input card 2x HDMI 1.4 connectors
2x DisplayPort 1.1 connectors
Dual Link DVI input card 2x Dual Link DVI-D connec tors
SDI input card
Note: Event Master currently s upports up to 3G-SDI formats.
6G-SDI may be supported in a future software release.
4x BNC connector supporting 6G-SDI
Genlock input 2x BNC connector (Input and loop output)
Supports black bur st* and tri-level analog signals
* All processors support black burst input; E X uses a regenerated genlock output and does not support black
burst output.
Depending on the m odel, each Event Master processor is shipped with the f ollowing input c ards:
Model Inputs via input cards
E2
• 28 inputs via 8 Ev ent M aster series input cards:
- Up to 8x 4K inputs – each outpu t card supports up to 4K@60p out
- 8x SD/HD/3G S DI (6G ready)
- 8x HDMI 1.4 (297 Mpix/sec ma x)
- 8x DisplayP ort 1 .1 (300 Mpix/sec m ax)
- 4x Dual Link DVI (330 Mpix/sec m ax)
E2Jr.
• 16 inputs via 4 Ev ent M aster series input cards:
- Up to 4x 4K inputs – each outpu t card supports up to 4K@60p out
- 4x SD/HD/3G S DI (6G ready)
- 6x HDMI 1.4 (297 Mpix/sec ma x)
- 6x DisplayP ort 1 .1 (300 Mpix/sec m ax)
S3–4K
• 12 inputs via 3 Ev ent M aster series input cards:
- Up to 3x 4K inputs – each outpu t card supports up to 4K@60p out
- 4x SD/HD/3G S DI (6G ready)
- 4x HDMI 1.4 (297 Mpix/sec ma x)
- 4x DisplayP ort 1 .1 (300 Mpix/sec m ax)
S3–4K Jr.
• 8inputs via 2 Ev ent Mas ter series input cards:
- Up to 2x 4K inputs – each outpu t card supports up to 4K@60p out
- 4x SD/HD/3G S DI (6G ready)
- 2x HDMI 1.4 (297 Mpix/sec ma x)
- 2x DisplayP ort 1 .1 (300 Mpix/sec m ax)
EX
• Two card slots, each of which may support any E 2 input or output card
- Up to 8 inputs via 2 input cards or 8 outputs via 2 output cards (same card s as E2 Event
Master processor)
(4 inputs a nd 4 o utputs, using one card of each type)
- Inputs can b e distributed to o ther processors via the link cable or to a locally installed
output card.
22 R5905948 EVENT MASTER DEVICES 17/07/2017
