15. EC-50 Maintenance
15.1 Servicing
General
Given the low failure r ate experienced on this device, it is ex tremely rare to have to change parts on the EC-50 controller.
In the unlikely event your EC series controller requires se rvice, please refer to the Return Material Authoriza-
tion section in t his manual prior to sending the unit b ack to the Barco Service Departm ent.
The only parts that the user may have to change by itself is the wo rk light and power fuse. The w ork light is a spare part provided
by Barco (see spare parts list bellow). The fuse is not provided by Barco.
EC-50 Overview
Orientation and main components.
Front:
Image 15-1
EC-50 controller (Front view)
1 work light connector
2 Touch screen
3 Buttons of presentation the presentation video controller
4 T-bar
Rear:
Image 15-2
EC-50 controller (Rear view)
1 Power switch
2 Power connector + fuse
3 work light connector
4 Communication connectors
478 R5905948 EVENT MASTER DEVICES 17/07/2017
