Barco S3 User Manual

3. General
An EX expansion box supports screen-destination program outputs and auxiliary ou tputs, up to a maximum total o f eight (8) v ideo
links (destinations or inputs) from ma in processor on a link cable to another expans ion box.
User interface
User interface Details
Event Master Software GUI based co nfiguration and control application
Cross platform (M ac/Windows)
Event Master Console EC-50 and EC-200 Dedicated hardware panels specifically designed to support
Event Master proc essors
Processing and latency
• 12 bits/color
•36bits/pixel
• 1 frame processing latency for progressive sources
PIP layers (per chassis)
Up to 32 P IP or Key overlay layers:
Model PIP layers
E2
• 2K mo de: 32x seamless PIP or Key overlay
• DL mode: 16x seamless PIP or Key overlay
• 4K m ode: 8x seamless PIP or Key overlay
E2 Jr.
• 2K mo de: 16x seamless PIP or Key overlay
• DL mode: 8x seamless PIP or Key overlay
• 4K m ode: 4x seamless PIP or Key overlay
S3–4K
• 2K m ode: 8x seamless PIP or Key overlay
• DL mode: 4x seamless PIP or Key overlay
• 4K m ode: 2x seamless PIP or Key overlay
S3–4K Jr.
• 2K m ode: 4x seamless PIP or Key overlay
• DL mode: 2x seamless PIP or Key overlay
• 4K m ode: 1x seamless PIP or Key overlay
EX NA
Background mixe r
Each P GM screen destination has an unscaled seamless bac kground mixer su pporting the full resolution of the destination
• Any live input type can be a background s ource
• Matte color generator
• Still store as background
Destinations (single chassis)
Model Destinations
E2
Eight (8) Program Outputs configurable as single screens o r tiled/blended widescreens.
E2 Jr.
Four (4) Program O utputs configurable as single s creens or tiled/blended widescreens.
S3–4K Four (4) Program O utputs configurable as single s creens or tiled/blended widescreens.
S3–4K Jr. Four (4) Program O utputs configurable as single s creens or tiled/blended widescreens.
EX NA
Program screens
Layout Mode
Model
Max. number of 4K outputs Max. number of Dual-Link outputs Max. number of HD (2K) outputs
E2
• 2x single s creens
• 1x blended (2 outputs)
• 4x single s creens
• 2x blended
• 8x single s creens
• 4x 2 output blende d (2 outp ut per
blend) up to 8x 1 output blended
24 R5905948 EVENT MASTER DEVICES 17/07/2017
