Barco S3 User Manual

3. General
Layout Mode
Model
Max. number of 4K outputs Max. number of Dual-Link outputs Max. number of HD (2K) outputs
E2 Jr.
• 2x single s creens
• 1x single s creen
(Has only one VPU bank; does not
support 4K blending.)
• 4x single s creens
• 2x blended
• 8x single s creens
• 2x 2 output blende d (2 outp ut per
blend) up to 4x 1 output blended
S3–4K
• 1x single s creens • 2x single s creens
• 1x blended
• 4x single s creens
• 2x 2 output blende d (2 outp ut per
blend) up to 4x 1 output blended
S3–4K Jr.
• 1x single s creens • 2x single s creens
• 1x blended
• 4x single s creens
• 2x 2 output blende d (2 outp ut per
blend) up to 4x 1 output blended
EX
• 2x single s creens
• 1x blended (2 outputs)
• 4x single s creens
• 2x blended
• 8x single s creens
• 4x 2 output blende d (2 outp ut per
blend) up to 8x 1 output blended
The EX ex pansion box can ha ve a combination of Input and Output cards, or it can have two V PU cards.
Auxiliary Outputs
Model
Auxiliary O utputs
E2
User definable from 12x 2048 x 1200 at 60 Hz to 3x 4K at 60 Hz
E2 Jr.
User definable from 8x 2048 x 1200 at 60 Hz to 2x 4K at 60 Hz
S3–4K User definable from 8x 2048 x 1200 at 60 Hz to 2x 4K at 60 Hz
S3–4K Jr. User definable from 4x 2048 x 1200 at 60 Hz to 1x 4K at 60 Hz
EX
User definable from 8x 2048 x 1200 at 60 Hz to 2x 4K at 60 Hz
Layer Mo de
Model
Max. number of 4K outputs Max. number of Dual-Link outputs Max. number of HD (2K) outputs
E2
• 3x Scaled AUX output • 6x Scaled AUX outpu t • 12x Scaled AUX output
E2 Jr.
• 2x Scaled AUX output • 4x Scaled AUX outpu t • 8x Scaled AUX output
S3–4K
• 2x Scaled AUX output • 4x Scaled AUX outpu t • 8x Scaled AUX output
S3–4K Jr.
• 1x Scaled AUX output • 2x Scaled AUX outpu t • 4x Scaled AUX output
EX
• 2x Scaled AUX output • 4x Scaled AUX outpu t • 8x Scaled AUX output
Multi-viewer
Output Resolution Max. Num ber of Outputs
HD (2K ) output
• 2x Multi-viewer output
Still store s
User-assigned still stores
• Live capture
• Loaded via PNG file
Presets
1,000 user definable presets
Expandability
Model
Chassis per system
E2
2 chassis per system—2x E2s , E2 & S3–4K, or E2 & 8x EX
E2 Jr. L inking is available as an upgrade option.
S3–4K 2 chassis per system —2x S3–4K s, S3–4K & E2, or S3–4K & 4x EX
R5905948 EVENT MASTER DEVICES 17/07/2017 25
