Barco S3 User Manual

3. General
3.3 Event Master controllers features
Connectivity
EC-30 EC-50 EC-200
USB connection from Event Master Toolset
host computer (OS X or Windows 7 and
higher)
USB connec tion from Event Mas ter
Toolset, either from a control computer or
the EC-200 controller
• 4 US B connectors in the back can be
used for k eyboard and mous e and
other supported USB devices.
• 1 U SB connector in th e middle of the
top of the console is o n delivery fitted
with a USB m emory.
NA DVI input for touchscreen monitor 2 connectors DVI-D (Screen output 1 and
2, internally 3 and 4)
NA NA 2 Ethernet connectors (outlet 1 to your
Event Master Device Network for static IP
address and outlet 2 for a DHCP assigned
IP address)
User controls
EC-30 EC-50 EC-200
• 24 assignable buttons with
customizable LCD displays
• 8 dedicated Layer selection buttons
and dedicated Background Layer
button
•12userdefinable Destination buttons
with multi-page functionality
• 2 User A ssignable Con textual Display
buttons
• 1 Cut button
• 1 All Trans button
• High -re so lut io n T-Bar
• 36 assignable buttons with
customizable LCD displays
• 8 dedicated Layer selection buttons
and dedicated B ackground Layer
button
•12user-definable Destination buttons
with multi-page functionality
• 4 User Assignable C ontextual Display
buttons
• 1 Cut button
• 1 All Trans button
• High-resolution T -B ar
• 1x Internal 15.6-inch wide touch
screen
• 36 assignable buttons with
custom iza ble LCD displays
• 8 dedicated Layer selection buttons
and dedicated Background Layer
button
• 12 user-d e finable Des tination buttons
with m ulti-page functionality
• 4 User Assignable Contextual Display
buttons
• 1 Cut button
• 2 All Trans buttons
• 1 On Screen K eyboard Button
• 1 Console Lock Button
• 1 Save All Button
• High-resolution T-Bar with
enable/disable button
• 1 S ystem Function Button Group
• 1 Direct Selection Bu tto n Grou p
• 1 Syntax Entry B utton Group
• 1 Nump ad
• 1 Contextual Display Button Gr oup
• 1 Live Func tion B utton Group
• 1 Arrow Button Group
• 1 Trackball with 4 modifier buttons
• 2 Barco Eye B uttons
• 5 Rotary Enc oders referred to as
wheels with m odifier buttons
• 1 F uture Expansion B utton Group
• 2x Internal 15.6-inch wide touch
screen
Dimensions and weight
EC-30 EC-50 EC-200
Dimensions
(HxWxD)
105.4 x 4 65.6 x 321.0 m m
4.15 x 18.33 x 12.63 inches
244.34 x 511.56 x 610.05 m m
9.62 x 20.14 x 24.02 inches
244.34 x 901.19 x 57 5.36 mm
9.62 x 35.49 x 22.65 inches
Weight
3.18 kg (7 lbs.) 12.33 kg (27.2 lbs.) 20.41kg (45 lbs.)
Screen
NA 1x Internal 15.6-inch wide touch
screen with 10 point mu lti-touch
2x Internal 15.6-inch wide touch
screens with 10 point multi-touch
R5905948 EVENT MASTER DEVICES 17/07/2017 27
