13. E2 Maintenance

Image 13-68

4. Turn the unit upside down and remove the bottom panel (Follow the instructions provided in th

e bottom panel removal section).

5. Locate the VFD cable that is plugged on the System-Power board.

Image 13-69

6. Pull the cable out of the unit .

How to install the V FD Cable

To install the VFD Cable follow the sam e pr ocedure in the reverse order.

R5905948 EVENT MASTER DEVICES 17/07/2017

395
