14. S3 Maintenance
Concerned parts
R767283K
Cable K it S et
Necessary tools
1 x Phillips Screwdriver #2 (to rem ove the front panel ass embly )
How to remove the USB Extension cable
1. Partially remov e the front panel assembly and pull it away to expose the cables behind it (refer to the related procedure).
2. Disconnect the USB E xtension cable from the USB cable.
3. Gently push the cable through the gromm et located in the 3RU Fan tray.
Image 14-37
4. Remove the 3RU Fan tray in order to a ccess the motherboard (refer to the r elated procedure).
5. Locate the USB E xtension cable that is plugged on the M otherboard.
Image 14-38
6. Unplug the U SB Extension cable by gently pushing it out.
7. Pull the cable out of the unit.
How to install the USB Extension cable
To install the USB Extension cable follow the same pr ocedure in the reverse order.
