4. Hardware orientation
The following sec tions describe each type of card in detail:
• "HDMI O utput Card", page 57
• "SDI O utput Card", page 58
Multiviewer (MVR) card
The Multiviewer card is physically identical to the HDMI output card, but when it’s plugged in the last s lot it operates as a Multiviewer
(MVR), supporting two (2) HD outputs. The Multiviewer ca rd is a dedicated, fully integrated monitoring solution that allows m ultiple
displays to be shown together on a single display. Up to 63 MVR windows (sources, backgrounds, clock, o r destinations) can be
displayed ac ross two (2) outputs: 63 windows for Inputs and 63 windows for Outputs.
From the Multiviewer menu in the EM GUI the us er can select from predefined layouts, or create custom ized layouts, texts, back-
grounds, bord ers, or colors for the monitors. The MVR includes several alarms such as Frozen and Loss-of-Signal indicators. For
more details on Multiviewer features, refer to the section "Multiviewer (M VR) Menu", page 192.
48
R5905948 EVENT MASTER DEVICES 17/07/2017
