4. Hardware orientation
Specifi ca tions
• DVI 1.0 Specification
• Maximum H Active: 4,096, Maximum V Active: 3,072
• Supported format:
- All single link DVI formats up to 165 MHz
- All d ual link DVI formats up to 330 M Hz
- 4K/UHD Supported:
o
3,840x2,160/ 23.98/24/25/29.97/30 input via 1x DVIDL, 2x DVISL (L and R half) or 4x D VISL (quadrants)
o
3,840x2,160/ 50/59.94/60 input v ia 2x DVIDL (L and R half) or 4x DV ISL (quadrants)
o
4,096x2,160/ 23.98/24/25/29.97/30 input via 2x DV ISL (L and R half) or 4x DV ISL (quadrants)
o
4,096x2,160/ 50/59.94/60 input v ia 2x DVIDL (L and R half) or 4x DV ISL (quadrants)
o
4,096x2,400/ 23.98/24/25/29.97/30 input via 2x DV ISL (L and R half) or 4x DV ISL (quadrants)
o
4,096x2,400/ 50/59.94/60 input via 2x DV IDL (L & R half) or 4x DV ISL (quadrants)
- EDID version 1.3 compatible
- HDCP version 1.4 c ompatible
DVI
Digital Visual Interface is a display interface developed in re sponse to the proliferation of digital flat panel displays.
The digital video connectivity standard that was developed by DDWG (Digital Display Work G roup). This c onnection
standard offers two different connectors: one with 24 pins that handles digital video signals only, and one with 29 pins
that handles both digital and analog video. This standard uses TMD S (Transition Minimize d Different
ial Signal) f rom
Silicon Image and DDC (Display D ata Channel) from VE SA (Video Electronics Standards A ss ociation).
DVI can be single or dual link.
52 R5905948 EVENT MASTER DEVICES 17/07/2017
