4. Hardware orientation
DisplayPort specifications
• DisplayPort per 1.1a s pecific ations
• Supported format:
- formats up to 2,560x1,600@ 60 and 3,840x1,200@60 (30 bits)
- 4K/UHD Supported:
o
3,840x2,160/ 23.98/24/25/29.97/30 via 1x DP, 2x DP ( L and R half) o r 4x DP (quadrants)
o
3,840x2,160/ 5 0/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
o
4,096x2,160/ 23.98/24/25/29.97/30 via 2x DP ( L and R half) or 4x DP (quadrants)
o
4,096x2,160/ 5 0/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- EDID version 1.3 compatible
- HDCP version 1.4 c ompatible
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncom pressed video
data and compressed/uncompressed digital audio data from a HDMI-com pliant device ("the source devic e") to a com-
patible computer monitor, video projector, digital television, or digital audio device. HDM I is a digital replacement for
existing analog video standards.
DisplayPort
Digital display interface developed by th e Video E lectronics Standards Association (VESA). This royalty-free interface
is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used
to transmit audio, USB, and other forms of data. V ES A designed it to replace VGA, DVI, and FPD-Link. Backward
compatibility to VGA and DVI by using active adapter dong les e nables users to use DisplayPort fitted video sources
without replacing ex isting display devices.
54 R5905948 EVENT MASTER DEVICES 17/07/2017
