3 VMA Mode

3.6 Occupied BW Measurement

State Saved Saved in instrument state

Min – /+(the maximum frequency of the instrument). That is, 27GHz max freq instrument has a CF step

range of +/- 27GHz. Note that this is the maximum frequency given the current settings of the

instrument, so in External Mixing, for example, it is the maximum frequency of the current mixer band

Status Bits/OPC

dependencies

non-overlapped

Full Span (Remote Command Only)

Changes the Occupied Bandwidth Span to show the full frequency range of the

instrument. It maximizes the span within a range but does not change Center

Frequency. When using external mixing, it changes the displayed frequency span to

the frequency range specified for the selected external mixing band.

Remote

Command

[:SENSe]:OBWidth:FREQuency:SPAN:FULL

Example

:OBW:FREQ:SPAN:FULL

Couplings Selecting full span changes the measurement span value

3.6.7 Marker

Accesses a menu that enables you to select, set up and control the markers for the

current measurement. If there are no active markers, Marker selects marker 1, sets it

to Normal mode (see "Marker Mode" on page 1007), and places it at the center of

the display. If the selected marker is Off, it is set to Normal and placed at the center

of the screen, on the trace determined by the Marker Trace rules.

3.6.7.1 Select Marker

Specifies the selected marker. The term “selected marker” is used throughout this

document to specify which marker will be affected when you change marker

settings, perform a Peak Search, etc.

This control appears above the menu panel, indicating that it applies to all controls

in the Marker menu panels. Select Marker is blanked if you select a tab whose

controls do not depend on the selected marker (for example, Counter).

For any menu that includes Select Marker, the first control is always Marker

Frequency | Time.

Notes The selected marker is remembered even when not in the Marker menu and is used if a search is done,

or a Band Function is turned on, or for Signal Track or Continuous Peak

1005 Vector Modulation Analyzer Mode User's &Programmer's Reference
