3 VMA Mode
3.4 IQ Waveform Measurement
Preset
Mode Value
5G NR, LTEA FDD/TDD Automatically calculated
BASIC 125.0 kHz
BASIC 100 MHz
EDGEGSM 637.5 kHz
MSR 125.0 kHz
PNOISE 125.0 kHz
WCDMA 125.0 kHz
WLAN 31.25 MHz
Min/Max 12.5 Hz/Option dependent
For Option DP2, B40 or wider IF Bandwidth option:
Digital IF 10 MHz path 12.5 MHz
Digital IF 25 MHz path 31.25 MHz
Digital IF 40 MHz path 50 MHz
Option B85 85 MHz path 106.25 MHz
Option B1A 125 MHz path 156.25 MHz
Option B1X 140 MHz path 175 MHz
Option B1Y 160 MHz path 200 MHz
Option B2X 255 MHz path 300 MHz
Option B5X 510 MHz path 600 MHz
Option R10 1 GHz path 1.2 GHz
Option R15 1.5 GHz path 2.4 GHz
Option R20 2 GHz path 2.4 GHz
Option R40 4 GHz path 5.1 GHz
For all other configurations:
10 MHz path 15 MHz
Option B25 25 MHz path 45 MHz
Meas Setup Summary Table
Lets you view and access many of the parameters in the Meas Setup menus on one
screen.
761 Vector Modulation Analyzer Mode User's &Programmer's Reference
