Keysight x-series Programmer's Reference

3 VMA Mode
3.1 Digital Demod Measurement
Multi Channel Config
This menu is only available for the Modulation Analysis measurement. It enables you
to configure multiple channel receiver. Different hardware platforms have different
parameters.
Input Channel IP address
Sets instrument IP address for channel configuration, “local” is used for current
instrument.
Remote Command
[:SENSe]:DDEMod:MCHannel:IPADdress1|2 <String>
[:SENSe]:DDEMod:MCHannel:IPADdress1|2?
Example
:DDEM:MCH:IPAD1 '192.168.1.2'
Preset Local
State Saved Yes
Backwards Compatibility
SCPI
[:SENSe]:DDEMod:MIMO:IPADdress1|2
Input Channel Instrument port
Remote Command
[:SENSe]:DDEMod:MCHannel:IPADdress1|2 <String>
[:SENSe]:DDEMod:MCHannel:IPADdress1|2?
Example
:DDEM:MCH:IPAD1 '192.168.1.2'
Preset Local
State Saved Yes
Backwards Compatibility
SCPI
[:SENSe]:DDEMod:MIMO:IPADdress1|2
Lock
Locks instrument and assigns to a channel in sequence.
Remote
Command
[:SENSe]:DDEMod:MCHannel:IPADdress1|2:LOCKed OFF | ON | 0 | 1
[:SENSe]:DDEMod:MCHannel:IPADdress1|2:LOCKed?
Example
:DDEM:MCH:IPAD1:LOCK 1
:DDEM:MCH:IPAD1:LOCK?
Preset 0
Vector Modulation Analyzer Mode User's &Programmer's Reference 372
