3 VMA Mode

3.1 Digital Demod Measurement

Remote Command

:CALCulate:DDEMod:LLINe[1]|2|…|6:OFFSet:UPDate

Example

:CALC:DDEM:LLIN:OFFS:UPD

State Saved No state

Delete Row

This is an immediate action control. It immediately deletes the currently-selected

row regardless of the row is being edited or not. The row following the currently-

selected row (or the row preceding if there is none) will be selected.

Delete Limit

Deletes the currently selected limit line. Pressing Delete Limit purges the data from

the limit line tables.

Limit data – including secondary parameters such as description, margin value, etc.

- will be cleared and returned to factory preset settings.

When this control is pressed, a prompt appears on the screen that says “Please

press Enter or OK to delete limit. Press ESC or Cancel to close this dialog.” The

deletion is only performed if you press OK or Enter; if so, after the deletion, the

informational message “Limit deleted” appears in the MSG line.

Remote Command

:CALCulate:DDEMod:LLINe[1]|2|…|6:DELete

Example

:CALC:DDEM:LLIN2:DEL

Deletes all data for limit line 2

Edit Trace Limit Settings

This is the second page of the Edit Trace Limits dialog. You access it by pressing

Settings on the Edit Trace Limits dialog.

Select Limit

Specifies the selected limit. The term “selected limit” is used throughout this

document to specify which trace limit will be affected by the functions.

Notes The selected limit is remembered even when not in the Limit Menu

Preset Limit 1, not affected by Mode Preset, preset by Restore Mode Defaults

State Saved Saved in instrument state

Vector Modulation Analyzer Mode User's &Programmer's Reference 382
