3 VMA Mode
3.8 ACP Measurement
:ACP:OFFS:INN:LIST:PREF:AUTO?
Dependencies Available only in LTEAFDD, LTEATDD and 5G NR Modes
Couplings When in the LTEAFDD, LTEATDD Modes, the inner power ref type is set automatically when the power
ref type state is auto according to the scopes of the sub-block gap in the following table
Sub-block Gap Inner ACP offset Power Ref Type
Wgap <5MHz 1st (2.5MHz) Normal
2nd (7.5MHz) Normal
5MHz≤ Wgap <10MHz 1st (2.5MHz) Cumulative
2nd (7.5MHz) Normal
10MHz≤ Wgap <15MHz 1st (2.5MHz) Cumulative
2nd (7.5MHz) Cumulative
15MHz≤ Wgap <20MHz 1st (2.5MHz) Normal
2nd (7.5MHz) Cumulative
20MHz≤ Wgap 1st (2.5MHz) Normal
2nd (7.5MHz) Normal
When in 5G NR Mode, Power Ref Type “Auto” sets the power reference type of inner-ACLR offset
automatically
Downlink: “Cumulative” or “Normal” is selected accordingly when the inner-offsets are configured to
meet the test requirements as follows:
FR1, 3GPP TS 38.141-1 v16.5.0 (2020-09) Section 6.6.3.5.3 BS type 1-C:
–
Table 6.6.3.5.2-3: Base Station ACLR limit in non-contiguous spectrum or multiple bands
–
Table 6.6.3.5.2-4: Base station CACLR limit
FR2, 3GPP TS 38.141-2 v16.5.0 (2020-09) Section 6.7.3.5.3 BS type 2-O:
–
Table 6.7.3.5.2-3: BS type 2-O ACLR limit in non-contiguous spectrum
–
Table 6.7.3.5.2-4: BS type 2-O CACLR limit in non-contiguous spectrum
Uplink: “Normal” is always selected
Preset When "Max Num of Offsets" on page 1285 is 12, the preset value of Offset G ~ L is the same as the
Offset F value
ON, ON, ON, ON, ON, ON | OFF, OFF, OFF, OFF, OFF, OFF
State Saved Saved in instrument state
Range
Auto|Man
Limit Test
This checkbox is the same as "Limit Test" on page 1307 in the Settings tab.
1323 Vector Modulation Analyzer Mode User's &Programmer's Reference
