Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
State Saved Saved in instrument state
Range Non-Overlapping | Overlapping All | Partially Overlapping
Subcarrier Count Per Channel Estimation Unit
For partially overlapping mode, specify subcarrier number of channel estimation unit
according to reference (preamble/pilot) overlapping pattern.
Remote
Command
[:SENSe]:OFDM:MIMO:PARTially:SUBCount <integer>
[:SENSe]:OFDM:MIMO:PARTially:SUBCount?
Example
:OFDM:MIMO:PART:SUBC 4
:OFDM:MIMO:PART:SUBC?
Preset 1
State Saved Yes
Min 1
Max 65536
Symbol Count Per Channel Estimation Unit
For partially overlapping mode, specify symbol number of channel estimation unit
according to reference (preamble/pilot) overlapping pattern.
Remote
Command
[:SENSe]:OFDM:MIMO:PARTially:SYMCount <integer>
[:SENSe]:OFDM:MIMO:PARTially:SYMCount?
Example
:OFDM:MIMO:PART:SYMC 2
:OFDM:MIMO:PART:SYMC?
Preset 1
State Saved Yes
Min 1
3.2.8.7 Advanced
Enables you to configure advanced parameters.
IF Gain
To take full advantage of the RF dynamic range of the analyzer, a switched IF
amplifier with approximately 10 dB of gain is available. When it can be turned on
without an overload, the dynamic range is always better with it on than off.
535 Vector Modulation Analyzer Mode User's &Programmer's Reference
