Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Pilot in Time Domain
Enables or disables the pilot in the time domain for phase tracking purpose. When
enabled, a single DFT is performed over all the Pilot and Data subcarriers in any
OFDM symbol, where no Preamble type of resource is allocated.
Remote
Command
[:SENSe]:OFDM:CCARrier0|…|7:PITDomain OFF | ON | 0 | 1
[:SENSe]:OFDM:CCARrier0|…|7:PITDomain?
Example
:OFDM:CCAR0:PITD 1
:OFDM:CCAR0:PITD?
Preset OFF
State Saved Saved in instrument state
MIMO On/Off
Turns MIMO on or off.
Remote Command
[:SENSe]:OFDM:MIMO[:STATe] OFF | ON | 0 | 1
[:SENSe]:OFDM:MIMO[:STATe]?
Example
:OFDM:MIMO OFF
:OFDM:MIMO?
Preset OFF
State Saved Yes
Range OFF|ON
MIMO Transmitter Antennas
Specifies the Transmitter Antennas for MIMO signal.
Remote Command
[:SENSe]:OFDM:MIMO:TXANtennas <integer>
[:SENSe]:OFDM:MIMO:TXANtennas?
Example
:OFDM:MIMO:TXAN 2
:OFDM:MIMO:TXAN?
Dependencies This control only appears when "MIMO On/Off" on page 531 is on
Preset 1
State Saved Yes
Min 1
Max 8
531 Vector Modulation Analyzer Mode User's &Programmer's Reference
