Keysight x-series Programmer's Reference

3 VMA Mode
3.2 Custom OFDM Measurement
Remote
Command
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN <real>
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN?
Example
:CALC:OFDM:MARK2:FUNC:BAND:SPAN 1.23E+06
:CALC:OFDM:MARK2:FUNC:BAND:SPAN?
Preset When marker is turned on, 1/20
th
of current span
State Saved Yes
Min 100
Max 9.9E+37
Interval Span
Sets the width of the span for the selected marker. This function defines the span of
time. The marker position does not change when you adjust the span.
Remote
Command
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:INTerval:SPAN <real>
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:INTerval:SPAN?
Example
:CALC:OFDM:MARK2:FUNC:INT:SPAN 1.23E+06
:CALC:OFDM:MARK2:FUNC:INT:SPAN?
Preset When marker turned on, 1/20
th
of current displayed time length
State Saved Yes
Min 100
Max 9.9E+37
Band Left/Interval Left
Band Left
Lets you adjust the left side of the band. In order to remain centered in the band, the
marker position must also change as you change the left edge. The right edge is
unaffected.
Remote
Command
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:BAND:LEFT <real>
:CALCulate:OFDM:MARKer[1]|2|…|12:FUNCtion:BAND:LEFT?
Example
:CALC:OFDM:MARK2:FUNC:BAND:LEFT 1.23E+06
:CALC:OFDM:MARK2:FUNC:BAND:LEFT?
Couplings Changes marker X to keep the marker centered in the band
Preset When marker turned on, 1/40
th
of current span left of the marker position
Vector Modulation Analyzer Mode User's &Programmer's Reference 486
