3 VMA Mode
3.1 Digital Demod Measurement
to configure the trace data. For example, the following command sets the first
window data to Spectrum.
:DISP:DDEM:WIND1:DATA SPEC
Use the SCPI command:
:DISPlay:DDEMod:WINDow[1]|2|…|6:FORMat <enum>
to configure the trace display format. For example, the following command sets the
first window trace display format to Constellation.
:DISP:DDEM:WIND1:FORM CONS
Use the SCPI command:
:DISPlay:DDEMod:WINDow[1]|2|…|6:SEGMent <enum>
to configure the trace data of which segment to be displayed. For example, the
following command sets the segment1 trace data to be displayed.
:DISP:DDEM:WIND1:SEGM SEGM1
3.1.3.1 Data
Provides a menu of trace data choices for the selected window.
Remote
Command
:DISPlay:DDEMod:WINDow[1]|2|…|6[:TRACe]:DATA RMTime | STIMe | TIME | SPECtrum
| MTIMe | RTIMe | MSPectrum | RSPectrum | EVTime | EVSPectrum | MERRor |
PERRor | CHFResponse | EQIResponse | DRESults | DBITs | ERESults | FRSummary
| CESymbol | NONE
:DISPlay:DDEMod:WINDow[1]|2|…|6[:TRACe]:DATA?
Example Set the second window data to SPECtrum:
:DISP:DDEM:WIND2:DATA SPEC
:DISP:DDEM:WIND2:DATA?
Notes The following aliases are supported:
Option Alias
MSPectrum MSPEectrum
RSPectrum RSPEctrum
DRESults DEMResults
DBITs DEMBits
Couplings Depends on window and modulation format
Preset Depends on window and modulation format
State Saved Yes
Range Raw Main Time | Search Time | Time | Spectrum | IQ Meas Time | IQ Ref Time | IQ Meas Spectrum | IQ Ref
Spectrum | Error Vector Time | Error Vector Spectrum | Mag Error | Phase Error | CH Freq Response | EQ
Impulse Response | Metrics | Demod Bits | EYE Diagram Metrics | Frame Summary | ccEVM vs Symbol |
No Data
Vector Modulation Analyzer Mode User's &Programmer's Reference 212
